Overview
Banner Q20 Series - Industry Standard Global Housing | WORLD-BEAM Family:
The new standard for industry-standard sensors. Banner's new WORLD-BEAM® Q20 delivers a host of sensing modes in a durable, IP67-sealed housing with industry-standard 25.4 mm mounting. The compact Q20 is the newest member of the World-Beam family of sensors, Banner's complete line of cost-effective, rugged and powerful photoelectric sensors.
Features:
Available in opposed, polarized and non-polarized retroreflective, and diffuse models
Photoelectric sensors in a compact, rugged, sealed, over-molded plastic housing
Standard 3 mm threaded mounting holes on 25.4 mm (1 in) spacing
Advanced electronic design for excellent noise immunity and cross-talk avoidance
Threaded metal M8 connector on Pico-style quick-disconnect models
Offers visible red beam for easy alignment on most models
Features bright LED status indicators visible from 360°
Provides water-tight, IP67 and NEMA 6 rated enclosure for rugged, reliable sensing
Rated to 1200 psi for washdown environments
Offers 10 to 30V dc supply voltage with complementary NPN or PNP outputs, depending on model
Provides versatile mounting options, including M3 (3 mm) threaded inserts with 25.4 mm hole spacing
Includes single-turn gain potentiometer for easy configuration, depending on model
10 V dc to 30 V dc operation with complementary solid-state outputs (1 normally open, 1 normally closed); PNP or NPN, depending on model
Complete offering of mounting brackets and apertures available
Crosstalk prevention filters available for visible red opposed mode pairs
Exceptional optical performance with easy to align visible red emitters
Background suppression models provide reliable detection up to 150 mm while ignoring objects in the background
Background Suppression Features:
Photoelectric sensors in a compact, rugged, sealed, over-molded plastic housing
Standard 3 mm threaded mounting holes on 25.4 mm (1 in) spacing
Simple single-turn potentiometer adjustment of cutoff distance from 30 to 200 mm
Enhanced immunity to fluorescent lights
Crosstalk immunity algorithm allows two sensors to be used in close proximity
High-intensity, bright red LED spot makes sensor alignment fast and easy
Bright indicator LEDs show operating status from 360°
Small bright red spot for reliable detection of colorfully printed packages and small parts or features
