Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Body Style | Rectangular |
| Connection | M12 |
| Connection Type | M12 4-Pin |
| Contact Configuration | NPN/PNP open collector outputs |
| Contact Rating | 250 mA at 10-40 Vdc |
| Current, Switching | 250 mA |
| Height | 1.81 Inch |
| Input Voltage | 10-40 Vdc |
| IP Rating | IP67 |
| Length | 4.01 Inch |
| Light Source | Visible Red |
| Maximum Operating Temperature | 55 C |
| Measurement Range | 4.9 m |
| Minimum Operating Temperature | -25 C |
| Number of Pins | 4 pin |
| Operating Temperature, Maximum | 55 C |
| Operating Temperature, Minimum | -25 C |
| Output | NPN/PNP |
| Protection | Output S/C, overcurrent and reverse polarity |
| Sensing Mode | Retroreflective Polarized |
| Sensor Type | Polarized Retroreflective |
| Series | |
| Supply Voltage | 40 VDC |
| Technology | Photoelectric |
| Type | Retroreflective Sensors |
| UPC Code | 782116111275 |
| Width | 1.91 Inch |
Overview
The new Enhanced versions of the Cutler-Hammer® 50 Series™ Photoelectric Sensors from Eaton's electrical business offer flexibility, durability and high optical performance in a cost-effective self-contained package. Choose from three output types, four sensing modes and three connection styles to tailor the sensor to exactly meet your needs. Sensors are available in thru-beam, reflex, polarized reflex, diffuse reflective, and clear object sensing modes. Brackets are available for easy mounting and to allow precise adjustment of sensor alignment.
