| Product Attribute | Attribute Value |
|---|---|
| Depth | 3.445" (87.5mm) |
| Dimensions | 150 x 94.5 x 87.5 mm |
| Family Name | Modicon Controllers Family |
| For Use With | Modicon M238 Logic Controller |
| IP Rating | IP67 |
| Length | 5.906" (150mm) |
| Mounting Type | DIN Rail Mount |
| Number of Outputs | 32 Output |
| Output Type | Transistor |
| Series | |
| Special Features | This Controller Can Service A Wide Range Of Application |
| UPC Code | 785901591153 |
| Width | 3.72" (94.5mm) |
Overview
Schneider Electric Modicon Twido Series | TM2 Input/Output Modules - Compact & Modular Base Programmable Controllers | Programmable Controllers for Standard Applications Comprising 10 to 100 I/O:
The Twido range of compact programmable controllers offers an “all-in-one” solution in a compact overall size: 80 to 157 x 90 x 70 mm. Eight compact base controllers (among which 4 expandable base controllers by addition of expansion I/O modules) are available, differing in their processing capacity and in their number of c 24 V inputs and number of relay and transistor outputs (10, 16, 24 and 40 I/O).
Among other diagnostics made, if the logic controller determines that there are I/O modules defined in the configuration that are not physically present on the I/O bus, an error is detected and the I/O bus does not start. With the Optional module feature, the logic controller ignores the absent I/O expansion modules that you have marked as optional, which then allows the logic controller to start the I/O expansion bus. The logic controller starts the I/O expansion bus at configuration time (following a power cycle, application download, or initialization command) even if optional expansion modules are not physically connected to the logic controller. Open to numerous communication networks, flexible due its 3 types of base (Compact, Modular) and wide range of I/Os, Twido and its associated TwidoSuite software provide simple and astute solutions for all your predicaments.
The range of TM2 expansion modules includes:
- Digital expansion modules
- Analog expansion modules
- Communication expansion module
- Expert expansion modules
Input/Output TM2:
The compact controller solution also allows great wiring flexibility. For discrete I/O expansion modules (with base controllers TWD LCpA 24DRF and TWD LCpp 40DRF) several possible types of connection are offered, such as removable screw terminal blocks and spring type connections which allow simple, fast and safe wiring. The Modicon Telefast ABE 7 pre-wired system allows the connection of modules with HE 10 connectors to pre-formed cables with free wires at one end for direct connection to sensors/preactuators, the Modicon Telefast ABE 7 pre-wired system for Twido controller (connection cable and ABE 7 sub-base assembly). The display and plug-in memory options allow easy adjustment, transfer and backup of applications the digital display can be used as a local display and adjustment tool, the EEPROM technology in the memory cartridges allows backup and transfer of programs to any Twido compact or modular controller. TwidoSuite software allows easy programming using instruction list language instructions or ladder language graphic objects.
